Adjustments

• Machine assisted user adjustments: Spring assisted seat

• Color coded pivots & points of adjustment: Yes

Frame & Cables

• Available frame colors: Iced Silver, Matte Black, Gloss Black, Lace White, Polarized Titanium

• Frame finish: Proprietary two-coat powder process

• Cable transmission: Internally lubricated cables & fittings

• Machine anchoring: Independent machine hold down brackets

• Integrated leveling system: Yes, top-down leveler

Tech Specs

• Overall “static” dimensions (L x W x H): 152 x 161 x 195 cm / 59.6” x 63.1” x 76.7”

• Overall “in-use” dimensions (L x W x H): 152 x 161 x 195 cm / 59.6” x 63.1” x 76.7”

• Product weight: 380 kg / 838 lbs

• Rep counter machine usage tracking: Service mode tracks total machine reps and hours of use

• Rep counter battery life: Approximately 3 years

• Rep counter power supply: 2 AA batteries

User Amenities

• Front placards: Muscle call outs, exercise specific stretching, start & finish exercise illustrations, proper machine adjustments, color-coded machine identification

• Rear placards: Color-coded machine identification, exercise specific stretching

• Placard color coding: Yellow (upper body)

• Rep counter: Electronic counter displays reps, exercise time and rest time

• Personal storage: Two tactile storage mats, personal device cradle and towel hook

• Action specific grips: Exercise specific grips improving feel, function and form during use

• Contoured seat: Yes

Weight Stack

• Total stack weight: 108 kg / 240 lbs

• Weight plate increments: 4.5 kg / 10 lbs

• Incremental weight system: 1.1, 2.3, 3.4 kg / 2.5, 5, 7.5 lbs

• Max training weight: 111.4 kg / 247.5 lbs

• Consistent 53” stack height: Yes

• Weight stack guarding: Full front and rear shields
